Bird Model 43 RF Wattmeter sn256838

€ 245,00
Incl. B.T.W.

Bird Model 43 RF Wattmeter CW field power measurement over 450 kHz to 1.2 GHz and 100 mW to 10 kW

Aantal

Item No
43
Item Name
General Purpose Wattmeter
Power Range
100 mW to 10 kW (using Bird® Plug-in Elements)
Frequency Range
450 kHz to 1.2 GHz (depending on element)
Insertion VSWR
1.05 max. to 1000 MHz (with N Connectors)
Accuracy
± 5% of full scale
Connectors
QC Type (Female N normally supplied)
Finish
Light Gray Powder Coat
Dimensions
(H x W x D)
6.88 in x 5.13 in x 3.63 in
(175 mm x 130 mm x 92 mm)
